RP SeriesPneumatic Mill Type Cylinder
200 PSI | Bore Sizes: 2″ to 20″
Specifications
Specification Overview
| Bore Size | 2” to 20” |
|---|---|
| Piston rod diameter | 5/8” to 5 ½” |
| PSI | 200 |
Material Overview
| Material Breakdown | STANDARD |
|---|---|
| Head & cap | Machined Steel |
| Barrel | Seamless Steel Tubing Honed ID *Optional Chrome Plating available |
| Barrel Seal | Nitrile O-Ring |
| Piston | Ductile Iron |
| Piston rod | Steel SAE 1045 |
| Gland | SAE 660 Bronze |
| High Temp | -29°C (-20°F) ~ 205°C (401°F) |
|---|---|
| Standard Temp | -50°C (-58°F) ~ 105°C (219°F) |
| Low Temp | -54°C (-65°F) ~ 60°C (140°F) |
Highlights
Design & Materials
Click on the (+) Icons to see more details.
Cap Screw | Grade 8
High Strength Nylon Wear Ring (2X) | BZ-PTFE for high temp version
High Load Piston Seal
Cushion Plunger | Floating cushion plunger provides maximum cushioning effect combined with a quick start for optimum performance
Cushion Valve | Fully retained for safety
Gland Retainer
Gland Bushing | Cartridge-type AL - bronze
Metallic Rod Scraper | (Standard) Rugged scraper deflects contamination away from the rod scraper for long service life
Rod Seal | PTFE - Low friction and long service life; Allows a fine film of oil to pass ensuring the necessary lubrication of the secondary seal; Geometry designed to vent pressure from the reverse side - to reduce possibility of pressure trap between seals.
RP Series Applications
Industries trust us to provide state-of-the-art actuation and automation solutions in the following sectors.
Oil and Gas
Empowering oil and gas operations with advanced valve automation, ensuring efficient flow control for upstream and downstream applications.
Chemical Processing
Maximizing chemical processing efficiency with cutting-edge automation and precision control technologies.
Mining & Processing
Boosting mineral processing productivity with innovative automation and control systems.
Water Treatment
Streamlining water treatment processes with advanced valve automation, such as regulating flow rates for precise flow control.
Power Generation
Enhancing power generation reliability through state-of-the-art valve automation, ensuring seamless operation of turbine control valves for optimized energy output.
Manufacturing
Revolutionizing manufacturing efficiency with precise actuation automation by optimizing the operation of advanced operations from aviation testing systems to industrial milling process control.
Datasheets & Videos
Limit Switches
Mechanical Limit Switch SPDT, for Open & Close Indication. Inductive switches also available. Solid State, Reed and inductive type also available. Specify brand and part number.
Available in 316 Stainless Construction
for corrosive applications. Includes attachments such as Rod clevis and Eye brackets.
GT3 Gland for Harsh Environments
Triple-seal gland with dual wipers. Rugged metallic scraper and urethane double-acting wiper deflect contamination away from the rod seal for long service life.
Balluff LDT
Optional Balluff LDT for continuous position feedback. 4-20mA, 0-10V and digital outputs available.
Designed and engineered for severe-service applications.
